Flexible Cables
Flexible Cables
450/750V 1-Core ~ 5-Core
EPR Rubber Insulated, Chlorinated Polyethylene Sheathed Neoprene Cable
Description: CU/EPR/CPE
Model Code: H07RN-F
Application
This flexible cable can be either installed as a fixed or mobile cable under adverse conditions such as in oily, acidic, or akaline environments, anti-UV and sunlight resistant.
Voltage rating
450/750V (0.6/1kV REF IEC 60092-353)
Construction
Plain annealed copper (IEC 60228 Class 5), EPR rubber insulated, chlorinated polyethylene (CPE) sheathed cable
Insulation colour
1-Core: White;
2-Core: Brown, Blue;
3-Core: Brown, Blue, Green/Yellow;
4-Core: Brown, Black, Grey, Green/Yellow;
5-Core: Brown, Black, Grey, Blue, Green/Yellow;
(Other colour upon request)
Sheath colour
Black
Specification
BS EN 50525-2-21, IEC 60332-1-2
Operating temperature
-25˚C to 90˚C
Certification
VDE
